This precision thermal testing equipment evaluates product resilience under extreme temperatures (up to +200°C), ensuring reliability for electronics, automotive, and aerospace components. Features rapid heating, uniform temperature distribution, safety protections, and compliance with IEC 60068/MIL-STD-810 standards.
Product Features
The high-temperature test chamber is an essential testing equipment in fields such as aviation, automotive, home appliances, and scientific research.
It is used to test and determine the parameters and performance of electrical, electronic and other products and materials after they undergo changes in the temperature environment during high-temperature or constant temperature tests.
Main Parameters
| Model | MHG-125 | MHG-270 | MHG-600 | MHG-1000 | |
| Test box size Width*Height*Depth (cm) | 50*50*50 | 60*90*50 | 100*1000*60 | 100*1000*100 | |
| Outer box size Width*Height*Depth (cm) | 70*125*60 | 800*165*60 | 125*185*75 | 125*180*115 | |
| Temperature range | RT + 10ºC~250ºC | ||||
| Natural capacity | Control accuracy | ±0.5ºC | |||
| Uniformity in the box | 100 ºC below is ±1.5ºC, 100ºC above is 2.5ºC | ||||
| Analysis accuracy | 0.1ºC | ||||
| Warm-up time | 60min | ||||
| Material | Outer casing | High-strength cold-rolled steel plate double-sided fine powder baking paint | |||
| Inner wall | SUS#201Stainless steel 2B Panel | ||||
| Insulation material | Fiberglass cotton | ||||
| System | Circulation fan | Extended shaft, high temperature resistant and increased efficiency motor + centrifugal fan | |||
| Heater | Nickel-chromium alloy electric heating wire accelerator | ||||
| Control method | PID control+SSR | ||||
| Power supply | AC220V 60/50 Hz | AC380V 60/50 Hz | |||
| Power supply (kW) | 6 | 9 | 12 | 12 | |
Notes:
1. The above dimensions are standard dimensions, and customization can also be carried out according to customer requirements.
2. The above performance data are measured in the effective space at a distance of 1/6 from each side of the inner chamber under no-load conditions when the ambient temperature remains at +25°C.
